Hydrodynamic Washing Unit for Oil Sludge
Technical Specifications of the Complex
The unit is a set of equipment designed to perform the hydrodynamic washing of oil sludge at an ambient temperature of no less than +10 °C.
Nominal capacity of the unit for processed raw material (depending on the composition of the raw material)
Up to 50 m³/day
Operating Mode
Cyclic
Minimum area required for the installation of technological equipment (m²)
60
Power supply voltage (V)
400
Maximum temperature in the hydrolysis chamber (°C)
50
Maximum power consumption
5 kW/hour
Normal 2 kW/hour
Composition of the Complex
1.Separation Reactor (AISI 304 steel)
2.Screw Mixer
3.Scraper Conveyor
4.Petroleum Product Receiving Tank
5.Control Panel and Instrumentation
Cost and Payment Terms
Cost of Manufacturing the Hydrodynamic Washing Unit for Oil Sludge: 250,000 EUR
The cost includes supervision of installation, equipment commissioning, and staff training.
Payment Terms:
• 60% advance payment.
• 30% after factory readiness.
• 10% after commissioning and startup works are completed.
